Waterbox Aquariums
AIO 65.4
• Height with Cabinet: 1350mm / 53.1"
• Display Volume: 249 L / 65.8gal
• Glass Thickness: 10mm
• Includes: Aquarium Filter Sock, Carbon, Bio Balls (Pump sold separately, Cabinet Optional)
AIO 65.4
No Cabinet
Kolibri Logistics
Transportweg 7
2742 RH Waddinxveen
Netherlands
AIO
All in one place.
An all-in-one aquarium that gives you more of what you love, in a larger more customizable design.
Aquarium
Built-in Filtration
The AIO™ filtration is designed to be used with freshwater and saltwater aquariums. The rear chambers allow for personalized use of media and reactors. The unique filtration and baffle system forces the water to travel through the filter socks and then flow into chambers adequately sized for multiple types of filtration media. This unique design also eliminates air bubbles in the system.
Y-Flow Nozzle
Features Y-Flow adjustable return nozzles for precise water agitation.
Filter Socks
Includes two 2.75” 225 Micron Filter Socks.
*AIO 65.4 has four 2.75” 225 Micron Filter Socks.
Stabilizing Leveling Mat
Relieves pressure points on the aquarium to ensure stability.
Ultra Low Iron Glass
Our aquariums are all manufactured using Low Iron Ultra Clear glass that is diamond beveled providing 91% transmittance.
High Strength Silicone
Manufactured using german made Wacker silicone will provide your aquarium with the longevity it needs.
Standard 90 Degree Joints
Manufactured using the standard aquarium manufacturing joints for maximum durability and strength.
Cabinetry
Strength & Stability
Aluminum Framed
Constructed with 20 mm aluminum framing to easily withstand the weight and humidity of your aquarium system.
Laminated Finish
Laminated wood panels skirt the aluminum framing for a sleek, modern look.
Adjustable Leveling Feet
An easy and effective way to ensure your aquarium is level, front to back and side-to-side.
Accessibility
The open back design allows for optimal ventilation and easy cord routing.
AIO Models
35 to 65 Gallons
AIO
Technical Specifications
| Product Model | AIO 35.2 | AIO 50.3 | AIO 65.4 | |
|---|---|---|---|---|
| Aquarium | Dimensions (Length x Width x Height) |
600 x 500 x 450mm | 900 x 500 x 450mm | 1200 x 500 x 450mm |
| 23.6"×19.7"×17.7" | 35.4"×19.7"×17.7" | 47.2"×19.7"×17.7" | ||
| Glass Thickness | 8mm (5/16") | 10mm (2/5") | 10mm (2/5") | |
| Water Height | 435mm/17.1" | 435mm/17.1" | 435mm/17.1" | |
| Aquarium Volume | 125 L/33 gals | 186 L/49.1 gals | 249 L/65.8 gals | |
| Aquarium Weight | 34.0 kg / 75.0 lb | 59.0 kg / 130.1 lb | 65.0 kg / 143.3 lb | |
| Glass Material | Ultra-clear glass | |||
| Transmittance | 91% | |||
| Filtration Chamber | 600 x 120 x 450mm | 900 x 120 x 450mm | 1200 x 120 x 450mm | |
| 23.6"×4.7"×17.7" | 35.4"×4.7"×17.7" | 47.2"×4.7"×17.7" | ||
| Filter Sock Chamber | 81 x 120 x 450mm | 81 x 120 x 450mm | 161x120x450mm |
|
| 3.2"×4.7"×17.7" | 3.2"×4.7"×17.7" | 6.3"×4.7"×17.7" | ||
| Filter Media/Skimmer Chamber | 101 x 120 x 450mm | 154 x 120 x 450mm | 150 x 120 x 450mm |
|
| 4"×4.7"×17.7" | 6.1"×4.7"×17.7" | 5.9"×4.7"×17.7" | ||
| Pump Chamber | 140 x 120 x 450mm | 300 x 120 x 450mm | 221 x 120 x 450mm | |
| 5.5"×4.7"×17.7" | 11.8"×4.7"×17.7" | 8.7"×4.7"×17.7" | ||
| Directional Nozzle | 1 | 2 | 2 | |
| Return Hose | Φ16 | Φ24 | Φ24 | |
| EVA Mat | 1 | 1 | 1 | |
| Filtration | Filter Socks | 70mm/2.75" x 2 | 70mm/2.75" x 2 | 70mm/2.75" x 4 |
| Filtration Sponge | 2 | 2 | 2 | |
| Bio ball | 24 pcs | 24 pcs | 48 pcs | |
| Cabinet | Cabinet Model | ALU 2420 | ALU 3620 | ALU 4820 |
| Cabinet Dimensions | 600 x 500 x 900mm | 900 x 500 x 900mm | 1,200 x 500 x 900mm | |
| 23.6" × 19.7" × 35.4" | 35.4" × 19.7" × 35.4" | 47.2" × 19.7" × 35.4" | ||
| Cabinet Framework | Anti-corrosion Aluminum Alloy | |||
| Door & Side Panels | 18mm PVC Laminated Wood Particle Board | |||
| Bottom Panels | 10mm PVC Board | |||
| Back Panels | 6mm PVC Board | |||
| Cabinet Color | WHT-White, BLK-Black, ASP-Aspen | |||
| SUS304 Hinges | ||||
| Leveling Feet | ||||
